Float Switches TSURUMI MF-3A (Mini-Float Sensor)

Float Switches TSURUMI MF-3A (Mini-Float Sensor)

The TSURUMI MF-3A Float Switches are designed to be as compact as possible. They are available in two types: contact “a” (normally-open) and contact “b” (normally-close). These switches are ideal for use in a maximum/minimum water-level alert system, and two floats can be used if the sensor is connected to a control panel for automatic pump operations.

These Float Switches have various applications, including automatic pumping of water and wastewater. They are also ideal for sensing alert water levels, such as high water levels or low water levels.

Additional information

Weight 1 kg
Dimensions 12 × 25 × 10 cm

฿2,520.00

Float Switches TSURUMI MF-3A (Mini-Float Sensor)

The TSURUMI MF-3A Float Switches are designed to be as compact as possible. They are available in two types: contact “a” (normally-open) and contact “b” (normally-close). These switches are ideal for use in a maximum/minimum water-level alert system, and two floats can be used if the sensor is connected to a control panel for automatic pump operations.

These Float Switches have various applications, including automatic pumping of water and wastewater. They are also ideal for sensing alert water levels, such as high water levels or low water levels.



Features

  • Simple structure made of a ball float with a shock absorber wrapped around it
  • Rugged construction withstanding impact from collision with the tank walls or piping
  • Assures trouble-free operations in the water containing any types of suspended solids including scum-filled wastewater
  • Switching on and off can be made at steadier angle than mercury type float switches
  • Contacts switchable, “a”(normally-open) or “b”(normally-close), at will

Applications

  • Automatic pumping of the wastewater containing lots of scum and suspended solids
  • For sensing alert water levels like high water level or lower water level

Specifications

รุ่น TSURUMI MF-3A
Electric
Characteristics
Breaking Capacity 50VA AC
Max.current 2A AC
Working voltage 30V AC
Switch Contact “a” (normally-open)
Type Microswith
Mechanical
Characteristic
Proof pressure
Static
98 kPa (1.0 kgf/cm2)
Working
Temperature Range
0 to 50 °C
Cable Cores x area 2 x 0.3 mm2
Outside Diameter 5.3 mm
Length 6 m
