The PEDROLLO HF70A is a 3 HP centrifugal pump designed for high-volume water transfer in agricultural and industrial systems. Built with cast iron for durability, it operates with 3-phase 380V power and supports high flow rates and continuous use.
Out of stock
The PEDROLLO HF70A centrifugal pump is engineered for applications requiring large volumes of water, such as agricultural irrigation and industrial water distribution. It features a durable cast iron body, supports a suction lift of up to 7 meters, and delivers up to 38 meters of head. With a 3 HP motor and 380V three-phase power, it ensures high performance for heavy-duty continuous operation.
| MODEL | POWER (P2) | m3/h | 0 | 3 | 6 | 9 | 12 | 15 | 18 | 21 | 24 | 30 | 36 | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Single-phase | Three-phase | kW | HP | △ | Q I/min | 0 | 50 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 500 | 600 |
| HFm 50B | HF 50B | 0.37 | 0.50 | IE2 | H metres | 10 | 10 | 9.5 | 8.5 | 7.5 | 6 | 4 | ||||
| HFm 50A | HF 50A | 0.55 | 0.75 | 12 | 12 | 11.5 | 11 | 9.6 | 8 | 6 | ||||||
| HFm 51B | HF 51B | 0.55 | 0.75 | IE3 | 18.2 | 17.2 | 16 | 14 | 11.5 | 9 | 5.4 | |||||
| HFm 51A | HF 51A | 0.75 | 1 | 21.2 | 20.2 | 19 | 17 | 14.5 | 11.6 | 8.4 | ||||||
| HFm 70C | HF 70C | 1.1 | 1.5 | 29 | 28 | 26.5 | 24.5 | 22 | 18.5 | 15 | ||||||
| HFm 70B | HF 70B | 1.5 | 2 | 33 | 32 | 30.5 | 28.5 | 26 | 22.5 | 19 | ||||||
| – | HF 70A | 2.2 | 3 | 39 | 38 | 36.5 | 34.5 | 32 | 28.5 | 25 | ||||||
| HFm 5C | HF 5C | 0.55 | 0.75 | IE2 | 12.5 | – | 12 | 11.7 | 11 | 10.2 | 9.2 | 8 | 6.5 | |||
| HFm 5B | HF 5B | 0.75 | 1 | IE3 | 13.7 | – | 13.2 | 13 | 12.5 | 11.6 | 10.5 | 9.2 | 8 | 5 | ||
| HFm 5A | HF 5A | 1.1 | 1.5 | 14.5 | – | 13.8 | 13.5 | 13.2 | 12.6 | 11.8 | 10.5 | 9.2 | 6.5 | 3 | ||
| HFm 5BM | HF 5BM | 1.1 | 1.5 | 19 | – | 18.5 | 18 | 17 | 16 | 15.2 | 14 | 12.8 | 9.7 | 6 | ||
| HFm 5AM | HF 5AM | 1.5 | 2 | 22 | – | 21.5 | 21 | 20.5 | 19.8 | 19 | 18 | 16.8 | 13.8 | 10 | ||
